Product Overview
Premium forged steel butt welded Y strainers provide superior particle filtration in permanent high-pressure piping systems. Featuring ASME B16.25 butt weld ends and ASTM A105/A182 forged construction, these heavy-duty strainers deliver maximum debris capture while minimizing pressure drop in critical oil & gas, petrochemical, and power generation applications.
Key Benefits
✔ Permanent Leak-Proof Connection – Butt weld integrity
✔ High-Pressure Capability – Rated to ASME Class 2500
✔ Optimized Flow Path – 45° Y-design reduces turbulence
✔ Easy Maintenance – Removable screen without pipe cutting
✔ Customizable Filtration – 10-200 mesh screens available
Advanced Features
360° Perforated Basket – Maximum filtration area
Blow-Out Proof Design – Secured screen retention
Magnetic Insert – Optional ferrous particle capture
Dual Drain Ports – For complete debris removal
High-Velocity Design – Reduced particle embedding
Performance Data
Screen Size Flow Capacity Pressure Drop
20 mesh (0.85mm) 100% Cv 0.2 bar
40 mesh (0.42mm) 85% Cv 0.5 bar
100 mesh (0.15mm) 60% Cv 1.2 bar
200 mesh (0.075mm) 40% Cv 2.5 bar
Industry Applications
Pipeline Systems – Pump protection, meter runs
Turbine Inlets – Steam/water particle removal
Compressor Stations – Gas stream filtration
Chemical Injection – Nozzle protection
Marine/Shipbuilding – Fuel oil filtration
Optional Features
- NACE MR0175 compliance
- Jacketed heating models
- Differential pressure gauges
- High-capacity basket designs
Why Choose Our Y Strainers?
✅ 50% Longer Screen Life – Reinforced basket design
✅ Zero-Leak Guarantee – Permanent welded joints
✅ Material Flexibility – Carbon steel to nickel alloys
✅ Global Certifications – ASME, PED, DNV, ABS
